Airport Aircraft Electric Baggage Tow Towing Port Terminal Tractor

Customization: Available
After-sales Service: 1 Year
Warranty: 1 Year

Product Description

i

Basic Info

Model NO.
TE-25-L-C
Transmission Type
Manual or Automatic
Power
Diesel or Electric
Load Capacity
31-40t
Emission Standard
Euro 1
Seats
≤5
Horsepower
150-250hp
Engine Capacity
4-6L
Tire Certification
ISO
Tire Design
Tubeless
Condition
New
Total Size
3170mm * 1440mm * 1960mm
📦

Packaging & Delivery

Package Size
320.00cm * 150.00cm * 200.00cm
Package Gross Weight
2500.000kg
Transport Package
Standard Export Packing
📝

Product Description

Our towing tractor includes airport towing tractor for luggage carts/dolly & aircraft towing tractor. The specially designed space makes the driver's work easier and more comfortable.

📊

Specification

Model TE-25-L
Performance Rated traction kN 21
Largest traction kN 25
Rated Towing Weight (dry concrete floor) kg 25000
Travel speed No-load gradeability Km/h 27
fully loaded Km/h 11
Minimum turning diameter mm 5900
No-load gradeability % 30
Recharge mileage Km 190
Weight Total Weight kg 3700
Unladen axle load Front axle kg 1430
Rear axle kg 2270
Battery Type Lithium iron phosphate
System Power Kwh 56
Rated Capacity Ah 700
Rated voltage V 80
📷

Product Gallery

🛡️

Safety Protection

  • Safety interlock mounted on each hydraulic.
  • Limit switch ensures the interface between platform and aircraft.
  • Warning buzzer alarms when van body & stabilizers are operated.
  • Emergency DC pump for engine or main pump failure.
  • Manual hand pump for total power failure situations.
  • Engine stop push buttons on cab and van body control panel.
  • Hydraulic pressure switch prevents raising unless stabilizers are down.

Why Choose Us

  • High quality products with reasonable pricing.
  • High standard production processes and advanced machinery.
  • Strict quality control and professional research team.
  • Experienced global exporting and professional sales support.
  • One-step solution service for all towing needs.
?

Frequently Asked Questions

What is the maximum traction capacity of the TE-25-L model?
The TE-25-L model provides a rated traction of 21 kN and a maximum traction capacity of 25 kN.
What kind of battery system does the electric tractor use?
It is equipped with a high-capacity Lithium Iron Phosphate battery system (80V / 700Ah) with 56 Kwh of power.
Can this tractor be used for both luggage and aircraft?
Yes, our towing tractor range includes models specifically designed for both luggage cart towing and aircraft ground handling.
What safety measures are in place for hydraulic failures?
The system includes safety interlocks on each hydraulic line, an emergency DC pump, and a manual hand pump to ensure operation during power or pump failures.
What is the recharge mileage and travel speed?
The tractor has a recharge mileage of approximately 190 Km and can reach a maximum no-load travel speed of 27 Km/h.
